DeepWorks SG-D1-Lite/SG-D2-Lite Portable Broadcast Control Server
★ The main screen features a 15.6-inch ultra-thin LCD display;
★ Built with a high-strength shock-resistant body, offering solid and stable structure;
★ Supports free construction of virtual studios with unlimited customizable layers;
★ Supports seamless switching between HDMI input, local media, network streams, and other multi-channel sources;
★ Portable director-style button layout allows quick adjustments for volume, transitions, recording, previewing, and more;
★ Integrates capture, editing, packaging, output, and broadcasting into one complete system—one machine covers all directing functions.
Description
VMEET E1 · Rugged Portable Broadcast System

Carry It Out.
Boot Up & Broadcast

15.6" rugged chassis, 8 shock-absorbing corner bumpers, 15 customizable LCD macro keys, built-in 12G-SDI and HDMI capture, up to 4× 4K@60 render outputs — the whole broadcast chain in one carry case.

8 Shock-Absorbing Corners 15 LCD Macro Keys 12G-SDI / HDMI Capture 380 × 300 × 90 mm
SG-D1-Lite rugged portable broadcast notebook, front view
15
custom LCD macro keys
4×
4K@60 render outputs (D2-Lite)
35.38MP
maximum pixel load
8
shock-absorbing corner bumpers
Highlights

Rugged outside. Broadcast-grade inside.

This is not a desktop console dropped into a case. It is re-engineered for rental work — constant transport and on-site delivery: shock-resistant structure, visual macro keys, professional capture and render chain.

High-strength rugged structure

A 15.6" high-strength portable rugged notebook chassis with a custom shock-resistant case and 8 silicone corner bumpers that cushion impact and absorb vibration on every load-in and every long haul.

RUGGED · 8 CORNERS

15 customizable LCD macro keys

Stream Deck visual macro keys with 15 function keys and unlimited paging. Icons and commands are fully configurable into your own switcher or control layout — volume, transitions, record and preview one touch away.

STREAM DECK · 15 KEYS

Professional capture & rendering

12G-SDI capture card (1× 12G-SDI + 1× HDMI input) accepts 4K@60 sources. D2-Lite adds 4× miniDP 1.4 render outputs, connecting straight to displays, LED sending cards or a video wall processor.

12G-SDI · 4K@60

Anti-mistouch cover

A cover over the control deck isolates the touchpad and shortcut keys when closed, so you can work directly on the notebook keyboard and avoid accidental scene changes mid-show.

ANTI-TOUCH COVER

VMEET E1 broadcast software

Capture, editing, graphics, output and playback in one chain — replacing the switcher, video processor, media server and control server. Standard on D2-Lite, optional on D1-Lite.

VMEET E1 · ALL-IN-ONE

Fits your existing workflow

Runs WatchOUT, vMix, Hirender S3, KYSTAR T3 and OBS Studio. Engineering and rental teams keep their current habits and get up to speed without retraining.

VMIX · WATCHOUT · OBS
SG-D1-Lite side view showing chassis thickness and I/O layout
Control

VMEET E1: capture to output, in one place

Dual scheduling modes and seamless source switching, paired with 15 macro keys, compress complex live direction into a single press.

01

Timeline & window scheduling

Two program scheduling modes — timeline and window — with graphic and text overlay plus fade effects. Build the playlist in advance and simply push it live on site.

02

Seamless source switching

Capture cards, NDI and network streams connect directly and switch seamlessly from dedicated keys — no external switcher on the table.

03

Stream · pull · record

Record, stream out or pull in streams, fully compatible with H.264, H.265 and HAP — ready for live platforms and playback terminals.

04

Lighting sync & multi-unit cascade

Art-Net support for pre-programmed lighting sync, TCP/UDP and DMX512 console control, multi-unit cascade, primary/backup mode and unattended operation.

Portability

Close the lid — it is a carry case

Closed size 380 × 300 × 90 mm, a reinforced rubber handle for one-hand carry, and screen latches that keep it shut in transit.

1Reinforced rubber handle

Centered weight distribution lets one person move it — no flight case or trolley for changeovers.

2Dual-side cooling ducts

Built-in air cooler with side fans and ducts keeps output stable through long hours at full load.

3Two screen latches

Dual latches secure the lid; together with the 8 silicone bumpers they take long-haul transport and constant loading.

43-pin waterproof aviation socket

220 V AC direct input with a 6 A power cord included — plug in and go.

SG-D1-Lite closed, showing the handle and cooling ducts
Scenarios

Six workloads built for rental and live

From stage shows to lecture capture, one rugged broadcast notebook covers framing, switching, graphics and output end to end.

01 / STAGE

Small & mid-size stage shows

Multi-camera switching plus LED content playback, with Art-Net lighting sync — one operator runs the show.

02 / CONFERENCE

Conferences & event streaming

Cameras, slides and players in, live graphic overlay, simultaneous streaming to online platforms.

03 / MOBILE STUDIO

Mobile studio

Pair with capture cards, encoders and cameras to build a virtual studio fast — OBS and vMix plug and play.

04 / EDU

Lecture capture

Routine and premium course recording; chapter-based timeline scheduling, recording and streaming at the same time.

05 / PERFORMANCE

Cultural performances

Batch-programmed playlists, one-key scene switching, media and lighting running in the same rhythm.

06 / EXHIBITION

Exhibitions & events

Looping booth playback and live streaming in parallel; unattended mode for long, stable runs.

Specifications

Technical specifications

Based on SG-D1-Lite; differences for SG-D2-Lite are marked in the tables.

Chassis & appearance

Ordering model Ruizhong SG-D1-Lite / SG-D2-Lite (rugged portable rental broadcast system)
Structure 15.6" high-strength portable rugged notebook structure, custom high-strength shock-resistant chassis, built-in air cooler
Display 15.6" LCD panel, VMEET E1 broadcast interface pre-installed
Keyboard / touch Industrial keyboard + industrial touchpad, with anti-mistouch cover (isolates touchpad and shortcut keys when closed)
Shortcut keys 15 customizable LCD function keys (Stream Deck visual macro keys, unlimited paging, customizable icons and commands)
Corners / handle 8 shock-absorbing silicone corner bumpers; 1 reinforced rubber handle; 2 screen latches
Indicators 4 device status LEDs; 1 power button
Closed size 380 mm × 300 mm × 90 mm
Operating system Windows 11 Pro

Video & audio interfaces

Render output D1-Lite: 1× HDMI 2.0 output (4K@60)
D2-Lite: 4× miniDP 1.4 render outputs (4× 4K@60) for displays or sending cards, plus 1× HDMI 2.0 output for a program monitor
Load capacity D1-Lite: 17.69 MP (2 × 4096×2160, max width 4096 px, max height 4096 px)
D2-Lite: 35.38 MP (4 × 4096×2160, max width 16384 px, max height 16384 px)
Capture 12G-SDI capture card: 1× 12G-SDI input + 1× HDMI input, 4K@60 audio/video synchronous capture
Audio 1× 3.5 mm audio output, 1× 3.5 mm microphone input
Network 1× 2.5G Ethernet port
USB 3× USB 3.2, 1× USB 3.2 Type-C (keyboard, mouse, flash drive and other peripherals)
Power input 3-pin waterproof aviation socket, 220 V~ 50/60 Hz AC input
Signal sources Capture cards, NDI, network streams; TCP/UDP, DMX512, Art-Net

Performance & software

Processor D1-Lite: AMD Ryzen 7 8700G, 8 cores / 16 threads, up to 5.1 GHz
D2-Lite: AMD Ryzen 7 7900X3D, 8 cores / 16 threads, up to 5.0 GHz
Graphics D1-Lite: Radeon 780M integrated graphics
D2-Lite: NVIDIA RTX A2000EM 8GB discrete + Raphael 2CU integrated
Memory 16 GB DDR5 (8 GB × 2)
Storage M.2 512 GB SSD
Power rating 300 W
Broadcast software VMEET E1 multimedia broadcast system (standard on D2-Lite; optional on D1-Lite, not included in the hardware-only version)
Codecs H.264, H.265, HAP and other common video codecs
Features Timeline / window program scheduling, graphic and text overlay, fade effects, streaming in and out, basic window slicing, primary/backup mode, unattended operation, multi-unit cascade
Third-party software WatchOUT, vMix, Hirender S3, KYSTAR T3, OBS Studio

Environment & packaging

Electrical AC 100–240 V, 50/60 Hz, max. 300 W
Operating 5–35 °C, 5%–95% RH (non-condensing)
Storage -10 °C to +60 °C, 0%–95% RH, non-condensing
Package size 510 mm × 440 mm × 220 mm
In the box Power cord ×1, manual, certificate of conformity, factory inspection report
Packing list Main unit ×1, 220 V 6 A power cord ×1, certificate of conformity, test report, function checklist, packing list
Usage note Operate the unit horizontally; do not turn it over or stand it vertically

* Specifications per SG-D1-Lite / SG-D2-Lite datasheet V1.0 (2026-10-20). The datasheet shipped with the unit prevails.

Models

Two configurations, chosen by load

Standard

SG-D1-Lite

Single 4K output and 17.69 MP load — a fit for conference streaming, lecture capture and small-to-mid events.

  • AMD Ryzen 7 8700G + Radeon 780M
  • 1× HDMI 2.0 output (4K@60)
  • 17.69 MP load (2 × 4096×2160)
  • 16 GB DDR5 / 512 GB SSD
  • Windows 11 Pro (VMEET E1 optional)
ProfessionalRecommended

SG-D2-Lite

Four 4K outputs and 35.38 MP load, with a discrete GPU and VMEET E1 standard — built for stage shows and multi-screen rental projects.

  • AMD Ryzen 7 7900X3D + RTX A2000EM 8GB
  • 4× miniDP 1.4 render outputs (4K@60)
  • 35.38 MP load (4 × 4096×2160)
  • 16 GB DDR5 / 512 GB SSD
  • VMEET E1 broadcast system included

Hardware-only option: SG-D1-Lite is also available without VMEET E1 (Windows 11 Pro only), for engineering and rental customers who already run their own broadcast software and need the hardware platform alone.
